کولرگازی لاویتا مدل Z4U20101013885 ظرفیت 30000Lavita Air Conditioner Model Z4U20101013885 Capacity 30000

30000 BTH

3.02 W/W

سرمایش و گرمایش

تک فاز

دارد

air throw: 10 m
Application area: 35~55 m2
Compressor/Brand: GMCC
Compressor/Model: PA270G2CS-4MUL
Compressor/Rated current(RLA): 10.8±5%
Compressor/Refrigerant oil/oil charge: 950 ml
Compressor/Type: Rotary
Cooling/Input: 2,910 W
Cooling/Rated current: 14.4 A
Design pressure: 4.5/1.9 MPa
Heating/Input: 2700W
Heating/Rated current: 13.3 A
Indoor air circulation Cooling/heating: 1300/1300 m3/h
Indoor coil/a Number of rows: 2
Indoor sound pressure(H/M/L/Mute): 51/46/39 dB(A)
Indoor unit/Dimension(W*D*H): 1200*340*260 mm
Indoor unit/Net/Gross weight: 16/20 kg
Indoor unit/Packing(W*D*H): 1265*415*338 mm
Operation temperature range: 16-31 °C
Outdoor coil/a Number of rows: 2
Outdoor noise level/ 62 dB(A)
Outdoor unit/Dimension(W*D*H): 953*433*808 mm
Outdoor unit/Net/Gross weight: 48/57 kg
Outdoor unit/Packing(W*D*H): 1020*475*860 mm
Power supply/Ph-V-Hz: 1Ph-220V-240V-50Hz
Qty 40 HQ: 126
Rerigerant piping/Liquid side/Gas side: 3/8 / 5/8 mm(Inch)
Rerigerant piping/Max. Difference in level: 5 m
Rerigerant piping/Max. rerigerant piping length: 15 m
نوع کمپرسور: روتاری (T1)

ندارد
