| سایر توضیحات(کولرگازی) | APPEARANCE/Indoor – Display: 88 Display
APPEARANCE/Indoor – Grille Front Look: Semi-R(silver)
APPEARANCE/Indoor – Remote Controller Type: Wireless LCD AKB75415305
APPEARANCE/Indoor – Remote: 4 Way
APPEARANCE/Indoor – Tool Code: SK
APPEARANCE/Outdoor – Condenser Type: Gold
APPEARANCE/Outdoor – Panel Type: Steel
APPEARANCE/Outdoor – Tool Code: U24A
FEATURE & FUNCTION/Functions – Airflow Direction Control(left & right): Auto
FEATURE & FUNCTION/Functions – Airflow Direction Control(up & Down): Auto
FEATURE & FUNCTION/Functions – Auto Changeover (Micom Control): Yes
FEATURE & FUNCTION/Functions – Auto Clean: Yes
FEATURE & FUNCTION/Functions – Deice Control(Defrost): Yes
FEATURE & FUNCTION/Functions – Display Light (On/Off): Yes
FEATURE & FUNCTION/Functions – Fan Speed (SH/H/MH/M/ML/L/SL): 7
FEATURE & FUNCTION/Functions – Hot Start: Yes
FEATURE & FUNCTION/Functions – Jet Cool Yes
FEATURE & FUNCTION/Functions – Natural Wind: Yes
FEATURE & FUNCTION/Functions – Restart Delay(minute): 3
FEATURE & FUNCTION/Functions – Self Diagnosis: Yes
FEATURE & FUNCTION/Functions – Setting Temperature Range (Cooling (°C)): 16-30
FEATURE & FUNCTION/Functions – Setting Temperature Range (Heating (°C)): 16-30
FEATURE & FUNCTION/Functions – Sleep Operation: Yes
FEATURE & FUNCTION/Functions – Soft Dry Operation: Yes
FEATURE & FUNCTION/Functions – Temperature Control: Thermistor
FEATURE & FUNCTION/Functions – Temperature Increment (°C): 1
FEATURE & FUNCTION/Functions – Timer: 24hr On/Off
FEATURE & FUNCTION/Functions – Vane Horizontal: Normal
FEATURE & FUNCTION/Ionizer – Plasmaster Ionizer: Yes
FEATURE & FUNCTION/Pre-Filter (in Front Grille) – Anti bacteria air filter: Yes (Top Filter)
FEATURE & FUNCTION/Special Function – Active Energy Control: I-Control Ampere
FEATURE & FUNCTION/Special Function – Fresh Dry: Yes
FEATURE & FUNCTION/Special Function – Indirect Air: Yes
FEATURE & FUNCTION/Special Function – Wi-Fi: Yes
GENERAL/Additional Refrigerant charge (g/m): 20
GENERAL/Air Flow Rate – Heating Indoor,Max (m3/min(CFM)): 19.5 (688)
GENERAL/Air Flow Rate – Heating Outdoor,Max (m3/min(CFM)): 49 (1730)
GENERAL/Compressor – Type: Dual Inverter Compressor
GENERAL/Cooling Capacity (T1) (Btu/h): 24,000
GENERAL/Cooling Capacity (T1) (kW): 7.03
GENERAL/Cooling Capacity (T3) (Btu/h): 20800
GENERAL/Cooling Capacity (T3) (kW): 6.1
GENERAL/COP (W/W): 3.21
GENERAL/Dimension – Indoor(W*H*D) (in.): 39.3*8.3*13.6
GENERAL/Dimension – Indoor(W*H*D) (inch): 42*11.1*16.8
GENERAL/Dimension – Outdoor(W*H*D) (in.) 34.3*25.6*13
GENERAL/Dimension – Outdoor(W*H*D) (in.): 40.9*27.9*17.9
GENERAL/Dimension – Package dimensions (mm): 1040*710*455
GENERAL/Dimension – Package dimensions (mm): 1071*282*428
GENERAL/Dimension – Product dimensions (mm): 870*650*330
GENERAL/Dimension – Product dimensions (mm): 998*210*345
GENERAL/Drain Hose(O.D, I.D) (mm(in)): 21.5,16.0 (0.85,0.62)
GENERAL/EER(T1/T3) ((Btu/h)/W): 10.30 / 7.50
GENERAL/EER(T1/T3) (W/W): 3.02 / 2.20
GENERAL/Heating Capacity (Btu/h): 24500
GENERAL/Heating Capacity (kW): 7.18
GENERAL/Max. Elevation Dierence (m(ft)): 25 (82)
GENERAL/Max. Piping Length (m(ft)): 30 (98.4)
GENERAL/Moisture Removal (l/h): 2.5
GENERAL/Net Weight – Indoor (kg(lbs)): 12.3 (27.1)
GENERAL/Net Weight – Outdoor (kg(lbs)): 45 (99.2)
GENERAL/Operation Range – Cooling(Indoor) (°C (°F)): 18 ~ 32 (64.4 ~ 89.6)
GENERAL/Operation Range – Cooling(Outdoor) (°C (°F)): 18 ~ 54 (64.4 ~ 129.2)
GENERAL/Operation Range – Heating(Indoor) (°C (°F)): 16 ~ 30 (60.0 ~ 86.0)
GENERAL/Operation Range – Heating(Outdoor) (°C (°F)): -5 ~ 18 (23.0 ~ 64.4)
GENERAL/Piping Connections – Gas Side (mm(in)): 15.88 (5/8)
GENERAL/Piping Connections – Liquid Side (mm(in)): 6.35 (1/4)
GENERAL/Power and Transmission Cable (N x mm2): 4*1.0 ( including Earth)
GENERAL/Power Factor – Cooling (%): 97.4
GENERAL/Power Factor – Heating (%): 97.4
GENERAL/Power Input (Heating) – Rated / Max (W): 2,240 / 3,700
GENERAL/Power Input (T1) – Rated / Max (W): 2,329 / 3,700
GENERAL/Power Input (T3) – Rated (W): 2773
GENERAL/Power Supply (Ø , V , Hz): 1Ø, 220-240V, 50Hz
GENERAL/Power Supply Cable (N x mm2): 3*2.5
GENERAL/Refrigerant & Charge (at 7.5 m) (g): R410A, 1400
GENERAL/RPM – Cooling (S-H/H/M/L/S-Low): 1600/1200/1000/850/700
GENERAL/RPM – Heating (S-H/H/M/L/S-Low): 1600/1200/1000/850/700
GENERAL/Running Curent (Heating) – Rated / Max (A): 10.00 / 17.00
GENERAL/Running Curent (T1) – Rated / Max (A): 10.4 / 17.00
GENERAL/Running Curent (T3) – Rated (A): 12
GENERAL/Set Weight – Indoor (kg(lbs)): 14 (30.9)
GENERAL/Set Weight – Outdoor (kg(lbs)): 49 (108)
GENERAL/Sound Pressure Level (Indoor) – Cooling, Max / H / M / L / SL (dB(A)+1): – / 44 / 41 / 37 / 28
GENERAL/Sound Pressure Level (Indoor) – Heating, Max / H / M / L (dB(A)+1): – / 44 / 41/ 37
GENERAL/Sound Pressure Level (Outdoor) – Cooling, Rated (dB(A)+1): 55
GENERAL/Sound Pressure Level (Outdoor) – Heating, Rated (dB(A)+1): 52
|
|---|
